Frame 29ER XC Full Carbon Hardtail Frame

Size Available 15/17/19/20.5”

Cable Routing 100% Internal Cable Routing

Weight 1100g/17"

Head Tube 1 1/2” – 1 1/2”

Seat Post Φ 27.2mm

Bottom Bracket Press Fit BB92

Tire Max 29er *2.3”

O.L.D TA Φ12*148mm

Max Chainring 32T (M9020 – B1 compatible)

Disc Brake Post Mount 160mm
